Mars photography by Mars Reconnaissance Orbiter

Mars Photography By Mars Reconnaissance Orbiter

The Ka-band subsystem was used for demonstration purposes. Due to lack of spectrum at 8.41 GHz X-band, future high-rate deep space missions will use 32 GHz Ka-band. NASA Deep Space Network (DSN) implemented Ka-band receiving capabilities at all three of its complexes (Goldstone, Canberra and Madrid) over its 34-m beam-waveguide (BWG) antenna subnet. During the cruise phase, spacecraft Ka-band telemetry was tracked 36 times by these antennas proving functionality at all antennas. Ka-band tests were also planned during the science phase, but during aerobraking a switch failed, limiting the X-band high gain antenna to a single amplifier. If this amplifier fails all high-speed X-band communications will be lost. The Ka downlink is the only remaining backup for this functionality, and since the Ka-band capability of one of the SDST transponders has already failed, (and the other might have the same problem) JPL decided to halt all Ka-band demonstrations and hold the remaining capability in reserve.
• Propulsion and attitude control
The spacecraft uses a 1,175 L (310 US gal) fuel tank filled with 1187 kg (2617 lb) of hydrazine monopropellant. Fuel pressure is regulated by adding pressurized helium gas from an external tank. Seventy percent of the fuel was used for orbital insertion.
MRO has twenty rocket engine thrusters on board. Six large thrusters each produce 170 N (38 lbf) of thrust for a total of 1,020 N (230 lbf) meant mainly for orbital insertion. These thrusters were originally designed for the Mars Surveyor 2001 Lander. Six medium thrusters each produce 22 N (5 lbf) of thrust for trajectory correction maneuvers and attitude control during orbit insertion. Finally, eight small thrusters each produce 0.9 N (0.2 lbf) of thrust for attitude control during normal operations.
