Panavia Tornado Combat Aircraft

Some Tornado variants carry different avionics and equipment, depending on their mission. The Tornado ECR is devoted to Suppression of Enemy Air Defences (SEAD) missions, operated by Germany and Italy. The Tornado ECR is equipped with an emitter-locator system (ELS) to spot radar use. German ECRs have a Honeywell infrared imaging system for reconnaissance flights. RAF and RSAF Tornados have the Laser Range Finder and Marked Target Seekers (LRMTS) for targeting laser-guided munitions. In 1991, the RAF introduced TIALD, allowing Tornado GR1s to laser-designate their own targets.
The GR1A and GR4A were equipped with TIRRS (Tornado Infrared Reconnaissance System), consisting of one SLIR (Sideways Looking Infra Red) sensor on each side of the fuselage forward of the engine intakes to capture oblique images, and a single IRLS (InfrarRed LineScan) sensor mounted on the fuselage's underside to provide vertical images. TIRRS recorded images on six S-VHS video tapes. The newer RAPTOR reconnaissance pod has replaced the built-in TIRRS system.
• Armament and equipment
The Tornado is cleared to carry the majority of air-launched weapons in the NATO inventory, including various unguided and laser-guided bombs, anti-ship and anti-radiation missiles, as well as specialised weapons such as anti-personnel mines and anti-runway munitions. In order to improve survivability in combat, the Tornado is equipped with onboard countermeasures, ranging from flare and chaff dispensers to electronic countermeasure pods that can be mounted under the wings. Underwing fuel tanks and a buddy store aerial refuelling system that allows one Tornado to refuel another are available to extend the aircraft's range.
